試題詳解

54. The following shows a rod of length L = 10.0 cm that is forced to move at constant speed v = 5.00 m/s along horizontal rails. The rod, rails, and connecting strip at the right form a conducting loop. The rod has resistance 0.400 Ω; the rest of the loop has negligible resistance. A current i = 100 A through the long straight wire at distance a = 10.0 mm from the loop sets up a (nonuniform) magnetic field through the loop. Find the emf. (μ0 = 4π10-7 T  m/A, ln 2 = 0.693, ln 10 = 2.303, ln 11 = 2.398)
(A) 2.4✖10^-4 V
(B) 5.8✖10^-3 V
(C) 4.8✖10^-5 V
(D) 3.9✖10^-4 V
(E) 8.8✖10^-4 V
